What is this?

A research prototype for the
factory of tomorrow.

Factory-X is a funded research project exploring how industrial machines can be monitored, operated, and understood remotely — using open standards, real-time data, and AI. Built by inovex, it runs as a live prototype against real infrastructure.

Digital Twin

Every machine has a standardised digital representation via the Asset Administration Shell (IEC 61360 / Industrie 4.0). Submodels describe identity, capabilities, and live state in a vendor-neutral format.

Real-time Telemetry

Machines stream live status, events, and operational metrics over MQTT (TLS-secured). The operator panel subscribes and reflects state changes in real time — no polling, no delay.

Remote Operations

Operators control and monitor machines from anywhere via the Remote Operator Panel — a web dashboard that unifies machine state, event logs, camera feeds, and digital twin data in one place.

AI Assistance

When machines fail, AI helps. The FX-Conductor connects operators to specialised knowledge bases (error codes, technical docs) via the Model Context Protocol — closing the gap between data and expertise.

Funded by the Federal Ministry for Economic Affairs and Climate Action (BMWK) and the European Union · NextGenerationEU as part of the Catena-X / Manufacturing-X initiative.

Services

Running Infrastructure

Next.js

Remote Operator Panel

fx-rop.com

Main dashboard for monitoring machines, browsing Asset Administration Shells, and managing operational data.

Open
Hono · MQTT

Machine Simulator 1

sim1.fx-rop.com

TruLaser3030 · machine-001. Simulates idle / executing / error / maintenance states, publishing live MQTT events.

Open
Hono · MQTT

Machine Simulator 2

sim2.fx-rop.com

TruLaser3030 · machine-002. Second machine instance for multi-asset testing and parallel MQTT streams.

Open
BaSyx 2.0

AAS Explorer

aas.fx-rop.com

Eclipse BaSyx 2.0 environment with MongoDB backend. Browse Asset Administration Shells, submodels, and properties for all registered assets.

Open
MCP · AI

FX Conductor

mcp.fx-rop.com

Model Context Protocol server bridging operators to specialised LLMs from Wittenstein and Trumpf — error codes, machine docs, and troubleshooting in context.

Open
Mosquitto · TLS

MQTT Broker

mqtt.fx-rop.com:8883

Eclipse Mosquitto 2, TLS-terminated at Traefik. Subscribe to live machine telemetry on factory-x/inovex/machines/#.

mqtts://mqtt.fx-rop.com:8883

System Design

Architecture

%%{init: {'theme': 'dark', 'themeVariables': {'primaryColor': '#1d71b8', 'primaryTextColor': '#fff', 'primaryBorderColor': '#c1d100', 'lineColor': '#a0c4e8', 'secondaryColor': '#0f4f87', 'tertiaryColor': '#071e33', 'background': '#071e33', 'mainBkg': '#0d2a45', 'nodeBorder': '#1d71b8', 'clusterBkg': '#0d2a45', 'titleColor': '#c1d100', 'edgeLabelBackground': '#0d2a45', 'fontSize': '18px'}}}%% graph LR OPS([Operator\nBrowser]):::user subgraph SIM_GROUP[" Simulators "] SIM1["Simulator 1\nsim1.fx-rop.com"]:::sim SIM2["Simulator 2\nsim2.fx-rop.com"]:::sim end subgraph BROKER_GROUP[" Broker "] MQ["Mosquitto\nmqtt.fx-rop.com:8883"]:::mqtt end subgraph PLATFORM_GROUP[" Platform "] ROP["Remote Operator Panel\nfx-rop.com"]:::rop MCP["FX Conductor\nmcp.fx-rop.com"]:::mcp AAS["BaSyx AAS\naas.fx-rop.com"]:::aas MONGO[("MongoDB")]:::db DB[("SQL DB")]:::db end subgraph EXT_GROUP[" External Systems "] PROALPHA["proAlpha\nERP"]:::ext PRENODE["Prenode\nVideo Streams"]:::ext EMPOLIS["Empolis\nKnowledge Portal"]:::ext end subgraph LLM[" LLM "] EMPOLISB["Empolis\nBuddy"]:::ext WITTENSTEIN["Wittenstein"]:::ext GEMINI["Gemini"]:::ext end OPS -->|Browser| SIM1 OPS -->|Browser| SIM2 OPS -->|Browser| ROP OPS -->|AI Chat| MCP SIM1 -->|MQTT publish| MQ SIM2 -->|MQTT publish| MQ MQ -->|subscribe| ROP ROP <-->|REST API| AAS AAS --- MONGO ROP --- DB ROP --> EMPOLIS ROP --> MCP PROALPHA -->|ERP| ROP PRENODE -->|Video| ROP MCP --> EMPOLISB MCP --> WITTENSTEIN MCP --> GEMINI classDef user fill:#c1d100,stroke:#a0b000,color:#1a1a1a classDef sim fill:#0f4f87,stroke:#1d71b8,color:#fff classDef mqtt fill:#0d2a45,stroke:#c1d100,color:#c1d100 classDef rop fill:#1d71b8,stroke:#a0c4e8,color:#fff classDef aas fill:#0f4f87,stroke:#1d71b8,color:#fff classDef db fill:#071e33,stroke:#1d71b8,color:#a8d8ff classDef ext fill:#1a3a1a,stroke:#4a8c4a,color:#a8d8a8 classDef mcp fill:#2d1a4a,stroke:#8b5cf6,color:#c4b5fd
Remote Operator Panel
Simulators / BaSyx
Operator / MQTT
External Systems
AI / MCP
Databases
